Dateq LPM 7

Submitted by Lead Flag

on 21-01-2020 22:25 Images: Lead

Upload additional Image

Model : LPM 7

Brand : Dateq
Brand website : www.dateq.nl

Category : Mixer

Availability : 1982 - 1991

This product has been discontinued

Vote :

Make FavouriteNobody voted this as Favourite Mixer yet.

OK we understand you don't like ads (so don't we) but,
Please consider making this website possible by disabling your Ad Blocker.
Or become a Gold Member, they don't see ads.

Product Information

Professional and modular build mixer.

Successor : Dateq LPM 7.2

Features

7 Channel Stereo Mixer
3 band EQ ±12dB per channel
Gain Trim per channel
Balance per channel
Low Cut(30Hz) rumble Filter
Peak LED
Each Channel seperate circuit board
PFL per channel
Inversed T-bar fader caps
12 Segment LED VU Bar Meter

Specifications

12 Inputs : 3 Phono(RCA), 7 Line(RCA), 2 Mic(Jack)
3 Outputs : Master(RCA), Mic Send, Headphones
Distortion(THD) : 0.015%
Signal to Noise : 95dB
Crosstalk : 66dB
Power Supply : 220 VAC 50/60Hz
Power Consumption : 20W
Dimensions (WxDxH): 483(19'') x 307 x 95mm
Cutout (WxD) : 443 x 284mm
Weight : 6.5 kg
