Model : LPM 7.4

Brand : Dateq
Brand website : www.dateq.nl

Category : Mixer

Availability : 2008 - Today ?

Vote :

Make FavouriteNobody voted this as Favourite Mixer yet.

OK we understand you don't like ads (so don't we) but,
Please consider making this website possible by disabling your Ad Blocker.
Or become a Gold Member, they don't see ads.

Product Information

The Dateq LPM 7.4, a 7 channel stereo mixer and now has 2 individual Master Outputs on XLR.

Predecessor : Dateq LPM 7.3

Features

There are a total of 21 audio inputs
Each of the 7 channels has 3 audio inputs , easily selected by a button
Large 2x 40 segment LED VU meter can be switched between master and PFL
All microphone inputs have Phantom power and the master features a noise gate
The internals are modulair setup for maximum mechanical durability
Send/Return

Specifications

Inputs (21): 11 Line (RCA), 3 Phono (RCA), 7 Mic (XLR)
Outputs (5): Master (XLR,RCA), Master2 (XLR,RCA), Monitor (RCA), Record (RCA), PFL (RCA, Jack)
Equalizers: 12kHz(12dB), 1400Hz(12), 50hZ(15dB)
Frequency Response: 20-25kHz
Distortion (THD): 0.007%
Power Supply: 230 VAC 50Hz
Power Consumption: 20W
Dimensions (WxDxH): 483(19'') x 355(8HE) x 107mm
Cutout (WxD): 448 x 335mm (+ space for connectors)
Weight: 6.4kg
