Model : AX700

Brand : JB Systems
Brand website : www.jb-systems.eu

Category : Amplifier

This product has been discontinued

Vote :

1 votes for Favourite Amplifier

8 DJ Booths with JB Systems AX700

8232
10303
8528
4927
9813

Show all 8 DJ Booths

OK we understand you don't like ads (so don't we) but,
Please consider making this website possible by disabling your Ad Blocker.
Or become a Gold Member, they don't see ads.

Product Information

Features
Professional amplifier for all-round sound reproduction
Short Circuit protection
DC current protection
High temperature protection
Forced fan cooling
Bridge function
Built-in limiters
Balanced XLR and Jack inputs
Ground/lift switch
Speakon® compatible speaker outputs
Binding post speaker outputs (screws)
Strong Aluminum 19” front

Specifications
Power stereo 4 ohm: 2x 350Wrms
Power stereo 8 ohm: 2x 200Wrms
Power bridge 8 ohm: 1x 700Wrms
Power parallel 2 ohm: ***
Freq. Resp. (+/-1.5dB): 10 - 50000Hz
Input Sensitivity: 0,77V
Input impedance: 20 kohm
S/R ratio: >85dB
Damping factor: >200
Slew Rate: 60V/uS
Cooling: Force Fan cooling
Inputs: Balanced XLR/Jack
Outputs: Speakon/binding post
Power supply: AC230V / 50Hz
Dimensions (mm): 88x483x260 (19'/2U)
