Pioneer Rekordbox  Music Management Software
This content is © 2014 The DJResource...Submitted by Lead Flag on 17-09-2009 @ 09:13Pioneer Rekordbox logoRekordbox is a music management software, you use it to prepare your tracks and export them to a USB Device to use it as playback source on a supported Pioneer CDJ-series CD player.

Pioneer Rekordbox software is a concept to organize the workflow of the DJ. In basics Rekordbox software is iTunes for DJs, your music management software. You can do everything you want with your Collection: organize it, sort it, make Playlists, Loops, Cue Points, Waveforms, etc. and store it in your Collection.

Click to Enlarge the Screenshot !!!When you want to play the tracks on your Pioneer CDJ-900 or Pioneer CDJ-2000 you select them in Rekordbox and export them to the USB device of your choice. Once inserted in a CDJ-900/2000 the CDJ will recognize the database (written by Rekordbox) and show you all the extra's.

Pioneer Rekordbox iconRekordbox is available for Mac and for PC. Rekordbox is not Mixing software, use Pioneer DJS or other mixing software instead. Not only the latest CDJ's (CDJ-900 and CDJ-2000) support Rekordbox but all future CDJ will do so as well.

As this topic is written on a PC platform, this topic refers to right click (for windows), if you are using a Mac platform do a CTRL-click instead.


Supported Players

feature Pioneer CDJ-900
feature Pioneer CDJ-2000


Rekordbox Workflow

Using Rekordbox is getting used to the workflow you should follow. Rekordbox works just like iTunes: you import the tracks (MP3, AAC, AIFF or WAV (16/24-bits)), playlists or even your Library from iTunes and sync (part of) the Collection with you mobile Device.


Pioneer Rekordbox workflow scematic


Import

You should import the files from the location where Rekordbox can always find them, preferable fixed hard drives. Importing tracks from small USB devices will not work as Rekordbox doesn't make a copy of the file but it only stores the file location in it's database. Tracks which cannot be found will be marked with a warning icon and are limited in it's handling's. A track that has the missing icon cannot be exported to a Device for use on a CDJ.

All imported tracks need to be analyzed first before they can be exported. When analyzing a track Rekordbox creates the waveform, measures the BPM and stores the ID3 tags in the database so you can browse them by tag.

How To : Importing tracks can be done on a few different ways. You can use the Import function from the File dropdown menu, you can drag-n-drop the tracks in the Collection Pane or you can import your iTunes library. You need to have some tracks imported before you can start organizing.


Organize

With Rekordbox you create a database of all the tracks you import/drag into it. In this database you can store 3 Hot Cue/Loops and 10 normal Cue/Loop Points per track. It also creates the Waveforms so they will show up instantly when used on a CDJ. Rekordbox creates a beat grit for each track (can be edited if necessary) so with the Quantize function activated all your Loop and Hot Cue Points are snapped to this grid and therefore always in sync (when you've made sure the grid has been aligned properly)

The edits you make to the tags in Rekordbox are also performed in the ID3 tag of the file on the original location. All the work of correcting your tags should be done once to save it for as lang as you've got the file itself. You can also add album art (also called Jacket Sleeve) to each file for easy recognition when browsing your Collection on the CDJ.

What to Do : All imported tracks are analyzed automatically or can be analyzed by right clicking it. Rekordbox also calculates the tempo of the tracks and positions the Beat Grid over it. Sometimes the Beat Grid needs fine tuning to gain accuracy. You also need to fill in the ID3 Tags in order to find your tracks easier by using the Search function on a supporting CDJ when browsing a USB Device.

You can adjust the Beat Grid by dragging the Needle to the proper position (Use zoom in if necessary) and right click anywhere on the gray Waveform. Then choose the last option: 'Adjust Beat Grid'. The nearest Beat Grid marker will now be shifted to the position of the Needle and the Beat Grid should be aligned properly now.

Edit the ID3 Tags with the Info Pane, these are directly saved to the files properties as well. Edit Genre, Album or any of the other track information. You can also give tracks a separate color or rating.

Hot Cue and normal Cue's can be made and stored with Rekordbox and are stored in your collection. When exported to a USB Device these will be added as well. When additional Cue/Loop information is found on the USB Device when inserted again in Rekordbox (made on a supporting CDJ), you can sync the new information with your Collection for reuse the next time.


Export

Make a selection of the tracks you want to have on your SD/USB Device and export them to the Device. Rekordbox software will now transfer (copy) the music files to the Device. It also makes a database for it (and on it) with the Waveform, Cue and Loop information. This can then be used on a CDJ that supports it.

How To : Just select a (collection of) tracks or playlists and right click the selected files. Then choose Export to, and select the proper device. Rekordbox will now export the tracks and/or playlist together with their Cue/Loop information and the Waveform. You can also drag the files on the Device in the Devices Pane to export them.



Layout and Functions

The Rekordbox interface exist of 2 parts, the top section of the screen is the Player, the bottom part below the gray waveform is the Music Database.



Pioneer Rekordbox workflow scematic


Player (top) Functions

The Player is used to play tracks that can be dragged in it from the Collection below. Most of your preparations will be made in the top section of Rekordbox and saved, ready for export to a Device for use on stage.

In the Player you can also :

feature Activate Quantize (snaps Hot Cues and Loops to Grid)
feature Adjust the Beat Grid (Right click, Adjust Beat Grid)
feature Set Loop Point (In and Out button)
feature Create Auto Loops (4-8-16-32 buttons)
feature Store Hot Cue/Loops (A-B-C buttons)feature Use the blue waveform to jump to a part of the track
feature Drag the gray Waveform to scrub the track
feature Store Cue Memory points (Memory Button)
feature Remove Hot Cue/Loops and Memory Points with the x-button besides it

With the 2 waveforms you can easily navigate to the section you want by clicking anywhere on the blue waveform. Then adjust the position by dragging the gray Waveform to the direction you like. You can also zoom in on the waveform for accurate positioning of the Cue/Loop Points

You can store 3 Hot Cue's and 10 Cue/Loop Memory Points per track. On your USB Device you can store banks of Hot Cues so basically there are endless possibilities to store you favorite point in the Device so you can recall them later.

Beat Grid Adjust

When analyzing your tracks Rekordbox also calculates the Beat Grid and overlays this on the audio. You can see the Beat Grid as whit markers that appear on every beat above the gray Waveform.

You can adjust the Beat Grid by dragging the Needle to the proper position (Use zoom in if necessary) and right click anywhere on the gray Waveform. Then choose the last option: 'Adjust Beat Grid'. The nearest Beat Grid marker wail now be shifted to the position of the Needle and the Beat Grid should be align properly now.


Lower Screen: Database

The lower section of Rekordbox is for your music management. This is where initially the most work needs to be done. As Rekordbox writes the tags you give tracks directly to the ID3 tags of the file so you only need to do things 1 time to keep your files updated as well. You can also use the Browser section to find and organize your tracks.

The small buttons with an arrow to the right are to display panes side by side. The main illuminated button is for the main part of the Browser, each button's arrow that is pressed puts that pane side by side the currently selected functions.

As seen in this screen shot you could see all panes at the same time but most of the time you will be using the Collection pane and the Info Pane.

The buttons on the left of the screen let you choose which function you'll seen in the main area of the Browser. Each of these functions will be shown and explained below, click the screenshots to enlarge them:


Click to enlarge Collection Screenshot

Collection

This is where you can browse your tracks. Before you can browse your tracks you need to import some. Importing tracks can be done on a few different ways. You can use the Import function from the File dropdown menu, you can drag-n-drop the tracks in the Collection Browser area or you can import your iTunes library.

On the top right of the screen is the Search box, this will perform a string search on the pattern you enter in the box. Press the icon that's on the left inside the Search box to select where should be searched (default is ALL).

With the little Category Button next to the Search box you can select the groups/categories of files you would like to see in the Browser. Selecting Genre, Artist or Album values only shows tracks that have the selected information. With 1 click you can see all your music from a specific music genre or from a specific artist.

The columns of the Collection can be adjusted in width, position or turned off. Right click the header of the columns and mark the columns you want to see. Drag the sides of the Column Header left and right to adjust the width of the column, just like in any other application on your computer. With the shown popup screen you can turn each column on or off. You can also drag the headers of the columns to reposition them. If you want the columns to auto-fit just right click the column header and choose 'Auto Size...'.


Click to enlarge Collection Screenshot

Bridge

The Bridge makes it possible to import your iTunes library to Rekordbox, including all playlists you've made. You can export your tracks to your iPod, but those tracks will be placed on the hard drive section of your iPod. Meaning that you can use the iPod (at least up to 5th generation) to store your tracks on, but those tracks CANNOT be played on the iPod itself. These files can only be accessed on the hard disk space by other devices.

You can import the files and the playlists from your iPod to the Rekordbox database or export a selection directly to a USB device.


Click to enlarge Collection Screenshot

Playlists

In Playlists you see the stored Playlists of your Collection. A Playlists can be added in Rekordbox (right click Playlist in the folder tree) or imported from a USB Device/iPod.

The History Playlist is stored at each performance (on a supporting CDJ configuration). Each Playlist can be renamed and transferred in the future to a USB Device for re-use of it. You can add a Playlist by right clicking the Playlist folder.

When you select one of the (History) Playlists the contents of that playlist will open in a browser on the right of the Playlists. This browser is identical to the Collection Browser and so are all things you can do with it.

If a Playlist is dragged (exported) to a Device, the tracks will be included automatically.


Click to enlarge Collection Screenshot

Hot Cue Banks

You have the possibility to store your favorite Hot Cue per track with the normal Hot Cue functions. But with the Hot Cue Pane you can store Hot Cue combination that have points across various tracks. You can now store your favorite Hot Cue/Loop combination from any position of any track in your Collection.

In Rekordbox right click the Hot cue Bank List' and add a Hot cue Bank List. You can assign any point in any track that's available to one of the Hot Cue Buttons (Press the A,B or C).

The Hot cue Bank panel can best be opened as a side panel for the Collection section. This way you can record directly into the selected Bank (Press any of the letters A, B or C to store the point)

Each set of Hot Cue points can be stored and renamed. When dragged to the Device to export it, the tracks will be included automatically as well.


Click to enlarge Collection ScreenshotDevices

This is where you can find the info of all connected devices that have Rekordbox exported files on them. You can browse all the files of the Device, the playlists and Hot cue Bank Lists.

Right click a device to update your Collection with the newly added (Hot)Cue's you've made during your gig. These will then be read and added to the files in your Collection.


Click to enlarge Collection ScreenshotInfo

This screen shows you all ID3 tag information for the tracks selected in another panel. You only use this panel by itself when you need more room when editing the tags.

The Summary tab shows some info, the Tags tab let's you edit the tags, tags in Rekordbox are directly written to the ID3 tag info of the file itself.

Drag you images to the Artwork tab and drop it in the Artwork box to add artwork to you files. These are shown in the display of the CDJ (if supported like CDJ-2000).

With the TAG tab opened you can directly edit the ID3 tags from your tracks. Once edited this will be written to the file as well. You don't need to press a submit button after editing, just hit an ENTER to confirm to changes or Escape to cancel them.



File Compatibility

You can playback music files in Pioneer Rekordbox that can also played by most supporting devices: MP3, WAV, AAC and AIFF files. These files can be stored on any of the above discs or on an SD card or USB device. A larger folder tree means more time is needed for the CDJ to read the folders, keep this as tidy as possible. In all three situations the following file limitations apply :

feature Folder tree is max. 8 levels deep

feature Max. number of folders on disc (CD/DVD) : 2.000
feature Max. files on disc (CD/DVD) : 3.000
feature Max. files per format (CD/DVD) : 999

feature Max. number of folders on media (SD/USB) : 10.000
feature Max. files on media per folder (SD/USB) : 10.000


Format Compatibility

CBR & VBR MP3 files [.mp3]

MPEG-1

Audio Layer-3 sampling with frequencies 32 kHz, 44.1 kHz, 48 kHz and a bit rate from 32 Kbps to 320 Kbps

MPEG-2

Audio Layer-3 sampling with frequencies 16 kHz, 22.05 kHz, 24 kHz and a bit rate from 16 Kbps (stereo) to 160 Kbps

AAC files [.aac .m4a .mp4]


MPEG-4 AAC LC

Sampling frequencies of 16kHz, 22.05kHz, 24kHz, 32kHz, 44.1 kHz, 48 kHz and a bit rate from 16 Kbps to 320 Kbps

ID3 Tags : Versions 1.0 / 1.1 / 2.2 / 2.3 / 2.4. Display will show Title, Album , etc. JPEG image embedded in ID3 tag is displayed as jacket photo.

WAV files [.wav]
Uncompressed

16-/24bit non compressed PCM format and sampling frequencies of 44.1kHz and 48kHz

AIFF files [.aif .aiff]

Uncompressed

16-/24bit non compressed PCM format and sampling frequencies of 44.1kHz and 48kHz
